Several Faults That May Occur in the Power System of Electric Pallet Stackers Apr 27, 2022

  It is inevitable for mechanical equipment to fail after long-term use, and it is no exception for electric stacker. It may also have certain faults when in use. Common power system failures are mainly manifested in non charging, low charging voltage and high charging voltage. Next, let's understand the reasons for these failures with EFORK:

1. Not charging


Fault phenomenon: when the engine of the electric stacker is working normally, the charging indicator light is on or the ammeter indicates a negative value direction, indicating that the generator does not generate electricity and the battery does not charge.

Fault cause: generator failure/regulator failure or electrical circuit failure, etc.

2. The charging voltage of the electric stacker is too low

Fault phenomenon: During the working process of the engine, the charging indicator light flashes or the ammeter swings around zero. Use the DC voltage range of the multimeter to measure the voltage value at both ends of the battery or generator.


Fault cause: the working voltage of the regulator is out of balance or faulty, the transmission belt is too loose, and the internal stator, rectifier, rotor and other components of the generator are faulty.

3. The charging voltage is too high

Fault phenomenon: the light bulb is easily burned during the working process of the stacker engine, and the battery electrolyte is consumed too fast. Use the DC voltage range of the multimeter to measure the voltage value at both ends of the battery or the engine. If it is higher than the standard value, it indicates that the charging voltage is too high.

Fault cause: the working voltage of the regulator is out of balance or faulty.


When using the electric stacker, you may encounter such faults of the electric stacker. In case of faults, you can check them in time according to the above reasons. If you can't solve them yourself, you can consult EFORK professional maintenance personnel.
